Pioneer PDP-433CMX Service Manual

49
PDP-433CMX
to :
RGB VIDEO Signal Waveforms
Measurement Point
Waveform at Power ON
Reset 2, D+2.5V, D+3.3V
V: 2V/div. H: 20msec/div.
A+3.3V, D+2.5V, D+3.3V
V: 2V/div. H: 50msec/div.
Wide UCOM, Reset 2, D+3.3V
V: 2V/div. H: 20msec/div.
IC100 clk, Reset 2, D+3.3V
V: 2V/div. H: 20msec/div.
to :
Input : INPUT 1 (Component)
Input Signal : 480i
Signal Pattern : H RAMP
Screen Mode : WIDE
Clamp Mode : AUTO
Color Mode : COLOR MODE 1
1 27
Measurement Condition
Input : INPUT 2 (RGBHV)
Input Signal : XGA@60Hz
Signal Pattern : Monoscope
Screen Mode : FULL
Clamp Mode : AUTO
Color Mode : COLOR MODE 1
28 29
to :
Input : INPUT 5 (DVI)
Input Signal : XGA@60Hz
Signal Pattern : Monoscope
Screen Mode : FULL
Clamp Mode : AUTO
Color Mode : COLOR MODE 1
30 31
to :
Input : INPUT 2 (RGBHV)
Input Signal : 1125i
Signal Pattern : Monoscope
Screen Mode : FULL
Clamp Mode : AUTO
Color Mode : COLOR MODE 1
32 33
IC4108
BA7657F
IC4402
CXA2101AQ
IC4403
6MLPF
IC4603
CXA3516R
IC5301
PD6357B
IC5001
PE5067
A-K
IC4803
PDY077
IC4802
M52346
SP
IC5505
M30624
FGAFP
CN5701CN5702
IC5702 IC5701
K4805 (HD_PLL) : For Horizonatal Sync. Signal
1
2
3
4
27
10
26
8
9
19 24
11 25
5
13
21
6
15
17
22
20
7
16
18
23
14
12
T1
T1
IC4802 - pin 13 : For Vertical Sync. Signal
T2
T2
Trigger Signal
I/O ASSY RGB ASSY
CN4103
CN4004
J5203
