50
PDP-433CMX
NO. Point Information Trigger Signal (CH4)
1 CN4103 - pin 2
Synchronize with K4805 (HD_PLL)
T1
2 CN4004 - pin 1
Synchronize with K4805 (HD_PLL)
T1
3 IC4402 - pin 17
Synchronize with K4805 (HD_PLL)
T1
4 IC4603 - pin 133
Synchronize with K4805 (HD_PLL)
T1
5 IC4603 - pin 70
Synchronize with K4805 (HD_PLL)
T1
6 IC5301 - pin 276
Synchronize with K4805 (HD_PLL) and frequency is 4 times.
T1
7 IC5701 - pin 30
Do not synchronize with K4805 (HD_PLL)
T1
8 IC4802 - pin 4
Synchronize with K4805 (HD_PLL)
T1
9 IC4802 - pin 15
Synchronize with K4805 (HD_PLL)
T1
10 IC4402 - pin 31
Synchronize with K4805 (HD_PLL)
T1
11 IC4603 - pin 113
Synchronize with K4805 (HD_PLL)
T1
12 IC4603 - pin 103
Synchronize with K4805 (HD_PLL)
T1
13 IC4603 - pin 101
No output
T1
14 IC4603 - pin 98
Clock signal that synchronizes with K4805 (HD_PLL)
T1
15 K5315 (HD_SEL)
Synchronize with K4805 (HD_PLL) and frequency is 4 times.
T1
16 CN5702 - pin 26
Do not synchronize with K4805 (HD_PLL)
T1
17 K5314 (DE_SEL)
Synchronize with K4805 (HD_PLL) and frequency is 4 times.
T1
18 CN5702 - pin 24
Do not synchronize with K4805 (HD_PLL)
T1
19 IC4803 - pin 140
Synchronize with K4805 (HD_PLL) and frequency is 1/4 times.
T1
20 K5317 (HD_SEL)
Synchronize with K4805 (HD_PLL)
T1
21 IC4803 - pin 11
Synchronize with IC4802 - pin 13
T2
22 K5316 (VD_SEL)
Synchronize with IC4802 - pin 13
T2
23 CN5702 - pin 28
Synchronize with IC4802 - pin 13
T2
24 IC4803 - pin 139
Synchronize with IC4802 - pin 13
T2
25 K4806
Synchronize with IC4802 - pin 13
T2
26 IC4402 - pin 31
Synchronize with IC4802 - pin 13
T2
27 K4603 (Y_SIGNAL)
Synchronize with IC4802 - pin 13
T2
28
K5314 (DE_SEL)
K5314 (DE_SEL) is fixed to "L" level in the PC signal indication. K5315 (HD_SEL) and
k 5317 (HD _ 30) synchronize with K5316 (VD_SEL).
K5316 (VD_SEL)
K5315 (HD_SEL)
K5316 (VD_SEL)
K5317 (HD_30)
29
K5314 (DE_SEL)
Magnified K5316 (VD_SEL) section of No. 28. K5315 (HD_SEL) and K5317 (HD _ 30)
are the same frequency in the PC signal indication.
K5316 (VD_SEL)
K5315 (HD_SEL)
K5316 (VD_SEL)
K5317 (HD_30)
30
K5314 (DE_SEL)
K5314 (DE_SEL) is not fixed to "L" level in the PC signal indication by the DVI input.
K5314 (DE_SEL), K5315 (HD_SEL) and k 5317 (HD_30) synchronize with K5316
(VD_SEL).
K5316 (VD_SEL)
K5315 (HD_SEL)
K5316 (VD_SEL)
K5317 (HD_30)
31
K5314 (DE_SEL)
Magnified K5316 (VD_SEL) section of No. 30. K5314 (DE_SEL), K5315 (HD_SEL) and
K5317 (HD_30) are the same frequency in the PC signal indication by the DVI input.
K5316 (VD_SEL)
K5315 (HD_SEL)
K5316 (VD_SEL)
K5317 (HD_30)
32
K5314 (DE_SEL)
K5314 (DE_SEL) is not fixed to "L" level in the 1125i indication. K5314 (DE_SEL),
K5315 (HD_SEL) and k 5317 (HD _ 30) synchronize with K5316 (VD_SEL).
K5316 (VD_SEL)
K5315 (HD_SEL)
K5316 (VD_SEL)
K5317 (HD_30)
33
K5314 (DE_SEL)
Magnified K5316 (VD_SEL) section of No. 32. Frequency of 2 times of K5314
(DE_SEL), K5315 (HD_SEL) and K5317 (HD_30) in the 1125i indication.
K5316 (VD_SEL)
K5315 (HD_SEL)
K5316 (VD_SEL)
K5317 (HD_30)
