8. EACH SETTING AND ADJUSTMENT
8.1 ADJUSTMENT REQUIRED WHEN THE UNIT IS REPAIRED OR REPLACED
1. At shipment, the unit is adjusted to its best conditions. Normally, it is not necessary to readjust even if an assembly is replaced. If the
adjustment is shifted or if it becomes necessary to readjust because of part replacement, etc., perform the adjustment as described below.
2. Any value changed in Service/Factory mode will be stored in memory as soon as it is changed. Before readjustment, take note of the
original values for reference in case you need to restore the original settings.
3. Use a stable AC power supply.
Y DRIVE Assy No adjustment required
Other assemblies No adjustment required
POWER SUPPLY Unit
DIGITAL Assy
X DRIVE Assy No adjustment required
Refer to “8.3 HOW TO CLEAR HISTORY DATA” and
“8.6 PRECAUTION ON REPLACEMENT OF THE
POWER SUPPLY UNIT”.
MAIN Assy (*) No adjustment required
Service Panel Assy Refer to “8.3 HOW TO CLEAR HISTORY DATA” and
“8.4
ADJUSTMENTS WHEN THE SERVICE PANEL
ASSY IS REPLACED”.
Writing of backup data is required.
Refer to the “8.2 BACKUP OF THE EEPROM
(DIGITAL ASSY)”.
PANEL SENSOR Assy Writing of backup data is required.
Refer to the “8.2 BACKUP OF THE EEPROM
(DIGITAL ASSY)”.
When any of the following assemblies is replaced
Note: Checking the Cable Card ID
The PDP has a slot for a cable card that is used for managing your
information by the cable TV company. The following procedure
allows you to check your Cable Card ID and the Host ID.
1. Press HOME MENU.
2. Select “Tuner Setup”. ( / then ENTER)
3. Select “Channel Setup”. ( / then ENTER)
4. Select “POD ID”. ( / )
• The Host ID and Cable Card ID appear.
5. Press HOME MENU to exit the menu.
(*) : When replacing the MAIN Assy, be sure to perform the FINAL SETUP.
