2.3 PANEL FACILITIES
Front Section
ON STANDBY SLEEP
5
Side
Side
6
4
3
2
1
7
9
10
11
8
13
12
15
14
16
1
1
button (This button is located on the bottom
on the rear panel (see on Rear section).
If the button is off, the power will not turn on
even when
TV
on the remote control unit or
STANDBY/ON
on the plasma display is
pressed. To turn on the power, press ).
2
POWER ON indicator
3
STANDBY indicator
4
SLEEP indicator
5
Room Light Sensor
6
Remote control sensor
7 STANDBY/ON
button
1
8 INPUT
button (
ENTER
button*)
9 VOLUME UP/DOWN
buttons (
UP/DOWN
buttons*)
10 CHANNEL UP/DOWN
buttons (
LEFT/RIGHT
buttons*)
11 TV GUIDE
button*
12
USB port
13
PHONES output terminal
14
INPUT 3 terminals (COMPONENT VIDEO: Y, P
B
,
P
R
)
15
INPUT 3 terminal (VIDEO)
16
INPUT 3 terminals (AUDIO)
The buttons with asterisks (*) can operate the TV Guide On
Screen™ system.
