9.3.14 FAY / FAN (ADJ. COMMANDS PERMISSION / PROHIBITION)
9.3.15 FAJ / UAJ / CBU / BCP (BACKUP FUNCTION FOR ADJUSTMENT VALUE)
The commands FAY/FAN are for prohibiting/permitting panel/MTB-adjustment commands.
Command
Format
Operation
Remarks
Effective Operation
Modes
Control
[FAY]
Normal operation mode
while the power is on
Adjustment command is valid.
For details, refer to the section “6.1.3 FUNCTIONS WHEN
ENTERING THE SERVICE FACTORY MODE”.
[FAN]
During FAY Adjustment command is invalid.
Command
Format
Operation
Remarks
Effective
Operation Modes
Control
[FAJ]
During FAY
To make the flag setting that indicating that adjustment of the panel
unit has been completed
This takes at least 350 mS.
[UAJ]
To make the flag setting that indicating that adjustment of the main
unit has not been completed
[CBU]
To make the flag setting that indicating that backup data have not
been copied
The backup ROM is
initialized.
[BCP]
To copy Digital backup data to EEPROM
When the DIGITAL Assy is to be replaced, adjustment values can be copied from the backup EEPROM to the EEPROM
of the Assy for service.
