< No. 8 Subcategory Information on "Failure in
IIC communication of MTB side" >
Value Shutdown Factor Remarks (Operation)
1 Tuner 1
2 MSP/MAP Shutdown
Shutdown
3 AV Switch Shutdown
4 RGB Switch Shutdown
5 VDEC Shutdown
6 VDEC-SDRAM Shutdown
7 AD/PLL Shutdown
8 HDMI Shutdown
A Tuner 2 Shutdown
B US-MSP Shutdown
< No. 7 Subcategory Information on "Failure in 3-wire
serial communication of Main microcomputer" >
Value Shutdown Factor Remarks (Operation)
1
Communication error of IF
microcomputer
Shutdown
2
Communication error of
sequence processor
Shutdown
< No. 10 Subcategory Information on "Abnormally in
FAN" >
Value Shutdown Factor Remarks (Operation)
1 FAN 1 Shutdown
2 FAN 2 (FHD only) Shutdown
< No. 12 Subcategory Information on "Failure in
Digital Tuner" >
Value Shutdown Factor Remarks (Operation)
1 DTV starting failure Turn off the screen,
then reset the
device.
2 DTV communication error
4 Abnormmaly in BCM7038
7 Tuner 1 or 2
8 Card I/F IC
9 VBI Slicer
C EEPROM
E TV Guide
G Home Gallery
H Middleware
I Application
< No. 13 Subcategory Information on "Failure in
Power supply at MTB side" >
Value Shutdown Factor Remarks (Operation)
1 RST 2 Shutdown
2 RST 4 Shutdown
