Pioneer PDP-5010FD Service Manual

PDP-5010FD
175
5678
56
7
8
C
D
F
A
B
E
(1) CHASSIS SECTION (1/2) PARTS LIST
(2) CONTRAST TABLE
PDP-5010FD/KUCXC and KUC are constructed the same except for the following:
Mark No. Description Part No.
1 FHD POWER SW Assy AWW1293
2 Ferrite Core (L1) ATX1044
3Housing Wire (J103) ADX3552
> 4 Fan Motor 80 x 25L AXM1058
> 5 DC Fan Motor 80 x 25L AXM1064
6 Front Chassis VL (508F) AMA1027
7 Front Chassis VR (508F) AMA1028
8Sub Frame L Assy 507 See Contrast table (2)
9Sub Frame R Assy 507 See Contrast table (2)
10 Front Chassis HT (508F) Assy ANA2092
11 Front Chassis HB Assy (50) ANA2094
12 Panel Holder V1 (50) ANG2770
13 Panel Holder V2 (50) ANG2771
14 Fan Holder ANG2833
15 Multi Base Holder ANG2937
16 Sub Frame Plate ANG3046
17 Floating Rubber 80 AEB1427
18 Ferrite Core Holder AEC1818
19 Reuse Wire Saddle AEC1945
20 Ferrite Clamp AEC1986
21 Reuse Wire Saddle AEC2118
22 Fan Holder AMR3704
23 Gasket ADH-FCH ANK1850
24 • • • • •
25 • • • • •
26 Screw See Contrast table (2)
27 Screw ABZ30P080FTC
28 Screw AMZ30P060FTB
29 Screw APZ30P080FTB
30 Screw PPZ50P100FTB
31 Screw TBZ40P080FTB
32 Screw ABA1364
Mark
No. Description Part No.
Mark No. Symbol and Description
PDP-5010FD
/KUCXC
PDP-5010FD
/KUC
8Sub Frame L Assy 507 ANA2080 ANA1945
9Sub Frame R Assy 507 ANA2081 ANA1946
26 Screw ABA1313 ABA1351
