PDP-5010FD
179
5678
56
7
8
C
D
F
A
B
E
(1) PANEL CHASSIS SECTION PARTS LIST
(2) CONTRAST TABLE
PDP-5010FD/KUCXC and KUC are constructed the same except for the following:
Mark No. Description Part No.
NSP 1 Panel Chassis (F) Assy AWU1234
NSP 2 50F ADDRESS L Assy AWW1310
NSP 3 50F ADDRESS S Assy AWW1311
NSP 4 50F SCAN A Assy AWW1312
NSP 5 50F SCAN B Assy AWW1313
NSP 6 50F SCAN C Assy AWW1314
NSP 7 50F SCAN D Assy AWW1315
NSP 8 Plasma Panel (50F) Assy AWU1235
9 PCB Spacer (Reuse) AEC2087
10 PCB Spacer (Reuse) AEC2122
11 Heat Radiation Sheet AEH1134
12 Conductive Plate Holder AMR3446
13 Address Plate (50F) A ANG3048
14 Address Plate (50F) B ANG3071
15 Conductive Plate X (F) ANG2906
16 Screw ABA1351
17 Screw ABA1364
18 Three Pieces Connector 40P AKM1384
19 Gasket AD ANK1948
20 Screw See Contrast table (2)
Mark No. Symbol and Description
PDP-5010FD
/KUCXC
PDP-5010FD
/KUC
20 Screw ABA1313 ABA1351
To Next Page
