PDP-5071PU
107
5678
56
7
8
C
D
F
A
B
E
6. DISASSEMBLY
6.1 PCB LOCATION
SIDE KEY Assy
SIDE Assy 50X SUB DRIVE
Assy
SENSOR Assy
50 ADDRESS
L Assy
50 ADDRESS
S Assy
50 ADDRESS
S Assy
SP TERMINAL
Assy
TANSHI Assy
50 LED Assy
LED IR Assy
50 ADDRESS
L Assy
50Y MAIN DRIVE Assy
50 SCAN B Assy50 SCAN A Assy
50 DIGITAL
Assy
MAIN Assy
AUDIO Assy
POD Assy
50 X MAIN DRIVE Assy
POWER SUPPLY
Unit
Front view
Rear view
Front view
50Y SUB DRIVE
Assy
