9.3.7 QPD
Data Arrangement
Data
Length
Output Example
ECO 3 Byte QPD
1 Latest "1st PD" data 1 Byte A
2 Latest "2nd PD" data 1 Byte 2
3 Data from the hour meter for the latest PD 8 Byte 00010020
4 Second latest "1st PD" data 1 Byte E
5 Second latest "2nd PD" data 1 Byte 9
6 Data from the hour meter for the second latest PD 8 Byte 00008523
7 Third latest "1st PD" data 1 Byte 4
8 Third latest "2nd PD" data 1 Byte 3
9 Data from the hour meter for the third latest PD 8 Byte 00004335
10 Fourth latest "1st PD" data 1 Byte 2
11 Fourth latest "2nd PD" data 1 Byte 0
12 Data from the hour meter for the fourth latest PD 8 Byte 00000945
13 Fifth latest "1st PD" data 1 Byte 4
14 Fifth latest "2nd PD" data 1 Byte 0
15 Data from the hour meter for the fifth latest PD 8 Byte 00000715
16 Sixth latest "1st PD" data 1 Byte A
17 Sixth latest "2nd PD" data 1 Byte 2
18 Data from the hour meter for the sixth latest PD 8 Byte 00000552
19 Seventh latest "1st PD" data 1 Byte A
20 Seventh latest "2nd PD" data 1 Byte 0
21 Data from the hour meter for the seventh latest PD 8 Byte 00000213
22 Eighth latest "1st PD" data 1 Byte D
23 Eighth latest "2nd PD" data 1 Byte 0
24 Data from the hour meter for the eighth latest PD 8 Byte 000001A7
CS 2 Byte 27
1, 2, 4, 5: PD data
0 No PD
1 Not used
2 P-POWER
3 SCAN
4 SCN-5V
5 Y-DRIVE
6 Y-DCDC
7 Y-SUS
8 Address
9 X-DRIVE
A X-DCDC
B X-SUS
C Not used
D Not used
E Not used
F UNKNOWN
Command
Format
Effective Operation
Modes
Function Remarks
[QPD] All operations
To acquire data on the power-down logs
Return data: 3 (ECO)+80(DATA)+2(CS)= 85 Byte
7 Acquisition of PD logs • • • [QPD]
The command QPD is for acquiring data from the 8 latest power-down (PD) logs.
