PDP-5071PU
179
5678
56
7
8
C
D
F
A
B
E
9.3.13 DRV
0 Non subcategory
1 Analog Tuner 1 (Front End 1)
2 Analog Tuner 2 (Front End 2)
3 MPX
4 AV Switch
5 RGB Switch
6 CCD
8 Main VDEC
A AD/PLL
B HDMI
G 64k EEPROM
H AUDIO IC
0 Non subcategory
3 DTV Device Error Device (immediately Power Supply OFF)
1 Failure to DTB Starting PS/RST (immediately Power Supply OFF)
FE1 (immediately Power Supply OFF)
FE2 (immediately Power Supply OFF)
AV-SW (immediately Power Supply OFF)
RGB-SW (immediately Power Supply OFF)
CCD (immediately Power Supply OFF)
M-VDEC (immediately Power Supply OFF)
ADC (immediately Power Supply OFF)
HDMI (immediately Power Supply OFF)
MA-FEP (immediately Power Supply OFF)
TV-G (immediately Power Supply OFF)
HOME-G (communication error (Retry 16
times) →Do not return after 2 times of soft
reset)
5 TV-Guide Error
7 Home Gallery Application comunication error.
1 DCDC Converter Power Supply reduced M-DCDC (immediately Power Supply
OFF)
2 Relay Power Supply reduced RELAY (immediately Power Supply
OFF)
<No.2 Subcategory Information on "failure in IIC communication of Main mircocomputer">
Data Cause of shutdown Remarks
<No.3 Subcategory Information on "Digital Tuner">
Data Cause of shutdown Remarks
<No.4 Subcategory Information on "POWER">
Data Cause of shutdown Remarks
7 DRV
Drive ON/OFF : ON/OFF control for only the large-power system
Format
Effective Condition
Function
Remarks
[DRV+S00]
[DRV+S01]
Every time
DRIVE OFF
DRIVE ON
At standby mode, when 10 seconds passed after
issuing [DRV+S00], command becomes invalid.
To Next Page
