PDP-5071PU
132
1234
1234
C
D
F
A
B
E
8.1.4 REMOTE CONTROL CODE
Remote control codes in Service Factory mode.
Muting Switching the main items Shifting to the next main item (top).
(DOWN) Switching the subtitled items. Shifting downward to the next subtitiled item.
(UP) Switching the subtitled items. Shifting upward to the next upper layer.
(LEFT) Decreasing the adjustment value. Decreasing the adjustment value.
ENTER/SET Switching the layers. Shifting downward or upward to the next lower or upper layer.
INPUT Selecting INPUT. Shifting the INPUT to the next function.
INPUTxx Selecting INPUT. Switching the INPUT to xx. (xx=1-6 etc)
CH+/P+ Increasing the channel number.
CH-/P- Decreasing the channel number.
Advanving.
Numeric keys Function: TV Function: TV(previously selected channel number is selected).
POWER Power OFF Turning the power off.
Factory ON(Non-Factory mode) In Non-Factory mode , turning Factory mode on.
HOME MENU *
1
Menu ON. In Factory mode , turning Factory mode off, and Menu mode on.
FACTORY Factory OFF(Factory mode) In Factory mode , turning Factory mode off.
VOLUME+ Volume UP. Increasing 10 the adjustment value. (PANEL FACTORY)
VOLUME- Volume DOWN. Increasing 10 the adjustment value. (PANEL FACTORY)
DRIVE ON/OFF *
2
Drive Mode OFF. Turning Drive mode off.
INTEGRATOR *
1
[ Note ] *
1
: A pertinent key that exists in the service remote control, becomes effective only in the factory and integrator mode.
Please use the remote control of the attachment when you normally operate it in the mode (home menu operation, etc.).
*
2
: When ten seconds have passed since the [ DRIVE ON/OFF ] key was pressed at the standby, it becomes invalid.
Please press [ POWER ] key from the [ DRIVE ON/OFF ] key pressing within ten seconds when you do power supply ON
while driven OFF.
INTEGRATOR MENU ON Enter INTEGRATOR MODE.
SR/R Keys Basic Functions Remarks
(RIGHT) Increasing the adjustment value. Increasing the adjustment value.
Remote Control Unit
for Servicing
To Next Page
