COMMANDS FOR PROHIBITION/PERMISSION OF DTV/HOMENET COMMUNICATION

7 Commands for prohibition/permission of DTV/HomeNet communication

Control device: DTV & HomeNet

Memory: ON/OFF of DTV communication prohibition mode

Applicable models: Only for models for North America

7 Functions

This is a command for forcibly prohibiting communication with DTV (for Elite series panels, communication using

HomeNet is included).

Normally, after the panel and the connected DTV are turned on, any operation is prohibited on the panel until startup of

the DTV is completed. However, on the production line, to avoid a drain on productivity, such waiting time must be

shortened. Thus, for the processes where the DTV is not necessary, such as panel adjustment, the existence of the DTV

can be ignored, to shorten waiting time.

7 Supplement

• While ZACS01 is established, the LED for ZAC flashes. The priority of LED indications is as follows:

PD > Trap-SW > DTV_STB > SD > ZAC >DTN > no backup copy > Standalone operation of the Assy > Normal ON/OFF

• Even if DTNS00 is established, if ZACS01 is established, DTV/HomeNet communication must be prohibited.

7 Operations

[DTNS01]

Factory Operation mode

Note: This command must be effective even if the Assy is used alone or installed in the unit.

• Having entered DTV/HomeNet Communication Prohibition mode must be stored in memory.

• The blue LED flashes rapidly to indicate that DTV/HomeNet Communication Prohibition mode is active.

• The next resetting of the main microcomputer is canceled, the main microcomputer judges that DTNS01 is established,

then communication with DTV/HomeNet will be prohibited. In such a case, any user operations (FAY command, etc.)

entered immediately after the unit is turned on must be effective. Also, any operations other than DTV/HomeNet

operations must be effective in the same way as during DTNS00.

[DTNS00]

Factory Operation mode

Note: This command must be effective even if the Assy is used alone or installed in the unit.

• Having entered DTV/HomeNet Communication Permission mode must be stored in memory.

• It is not necessary to immediately restore communication with DTV/HomeNet. DTV/HomeNet communication must be

restored until resetting of the main microcomputer is canceled next time.

7 Commands

DTN

S00 To exit DTV/HomeNet Communication

S01 To enter DTV/HomeNet Communication
