Pioneer PDP-5071PU User Manual

PDP-5071PU
27
5678
56
7
8
C
D
F
A
B
E
3. PCB PARTS LIST
Parts marked by "NSP" are generally unavailable because they are not in our Master Spare Parts List.
The mark found on some component parts indicates the importance of the safety factor of the part.
Therefore, when replacing, be sure to use parts of identical designation.
When ordering resistors, first convert resistance values into code form as shown in the following examples.
Ex.1 When there are 2 effective digits (any digit apart from 0), such as 560 ohm and 47k ohm (tolerance is shown by J=5%,
and K=10%).
Ex.2 When there are 3 effective digits (such as in high precision metal film resistors).
561
473
R50
1R0
5621
NOTES:
560 Ω
47k Ω
0.5 Ω
1 Ω
RD1/4PU J
RD1/4PU J
RN2H K
RS1P K
56 x 10
1
47 x 10
3
R50
1R0
561
473
5.62k Ω RN1/4PC F562 x 10
1
5621
Mark
No. Description Part No.
LIST OF ASSEMBLIES
NSP 1..PANEL CHASSIS (507) ASSY AWU1148
NSP 2..50 ADDRESS ASSY AWV2303
NSP 3..50 ADDRESS L ASSY AWW1141
NSP 3..50 ADDRESS S ASSY AWW1142
NSP 2..50 SCAN ASSY AWV2304
NSP 3..50 SCAN A ASSY AWW1147
NSP 3..50 SCAN B ASSY AWW1148
NSP 1..50 X DRIVE ASSY AWV2305
2..50 X MAIN DRIVE ASSY AWW1143
2..50 X SUB DRIVE ASSY AWW1144
NSP 1..50 Y DRIVE ASSY AWV2306
2..50 Y MAIN DRIVE ASSY AWW1145
2..50 Y SUB DRIVE ASSY AWW1146
NSP 1..50 DIGITAL ASSY AWV2302
2..50 DIGITAL ASSY AWW1139
2..SENSOR ASSY AWW1140
1..MAIN ASSY (US BB) AWV2312
NSP 1..I/O ASSY AWV2313
2..POD ASSY AWW1154
2..TANSHI ASSY AWW1156
2..SIDE ASSY AWW1157
NSP 1..50 AUDIO FUKUGO ASSY AWV2346
2..AUDIO ASSY AWW1131
2..SP TERMINAL ASSY AWW1132
2..SIDE KEY ASSY AWW1133
2..50 LED ASSY AWW1135
2..LED IR ASSY AWW1136
> 1..POWER SUPPLY UNIT AXY1153
Mark
No. Description Part No.
50 DIGITAL ASSY
[DIGITAL IF BLOCK]
MISCELLANEOUS
F3001 CCG1162
CN3001 50P CONNECTOR AKM1353
CN3002 20P FFC CONNECTOR AKM1235
RESISTORS
R3007, 3010–3016 RAB4C470J
R3020–3022 RAB4C103J
Other Resistors RS1/16SS###J
[MODULE UCOM BLOCK]
SEMICONDUCTORS
IC3151 AGC1011
IC3152, 3153 SN74AHC541PW
IC3155 SN74AHC08PW
IC3156 BR24L04FJ-W
IC3157 M62334FP
IC3159 TC7W126FU
IC3160, 3161 TC74VHC123AFTS1
Q3151 2SJ461A
D3151, 3152, 3154, 3155 DAN202U
D3158, 3159, 3161–3163 1SS355
MISCELLANEOUS
X3151 CSS1616
CN3151 CONNECTOR AKM1276
CN3152 CONNECTOR CKS4828
RESISTORS
R3155, 3160, 3170, 3176 RAB4C101J
R3174 RAB4C103J
Other Resistors RS1/16SS###J
CAPACITORS
C3151 CEHVKW470M6R3
C3152, 3153, 3155–3158 CKSSYB104K10
C3159, 3171, 3172, 3182 CKSRYB105K6R3
C3162, 3163, 3165, 3166 CKSSYB104K10
C3164 CCSSCH101J50
C3167 CKSSYB103K16
C3168, 3170, 3181 CKSSYB104K10
[PANEL FLASH BLOCK]
SEMICONDUCTORS
IC3301 AGC1009
IC3302, 3305 PST3628UR
IC3303 SN74AHC08PW
IC3304 PST3610UR
Q3301 RN1901
Q3302 HN1C01FU
MISCELLANEOUS
X3302 ASS1188
CN3301 CONNECTOR CKS4835
RESISTORS
R3307, 3308 RAB4C101J
Mark No. Description Part No.
