Other Resistors RS1/16SS###J
CAPACITORS
C3301–3303, 3306, 3308 CKSSYB104K10
C3304, 3307, 3309 CKSSYB472K16
C3305, 3310 CKSSYB102K50
C3311 CCSRCH470J50
C3315, 3316 CKSSYB104K10
C3317 CCSRCH471J50
[SQ ASIC BLOCK]
SEMICONDUCTORS
IC3401 PEG239A
MISCELLANEOUS
L3401–3403 QTL1013
F3401, 3402 CCG1162
RESISTORS
R3402, 3412 RAB4C101J
R3405–3407, 3409, 3410 RAB4C220J
R3416 RAB4C220J
R3425 RS1/16SS5601F
Other Resistors RS1/16SS###J
CAPACITORS
C3401, 3402, 3419, 3425 CEHVKW101M6R3
C3403–3413, 3417, 3418 CKSSYB104K10
C3420–3424, 3426–3432 CKSSYB104K10
C3445–3448 CKSSYB104K10
[ADDRESS CN BLOCK]
SEMICONDUCTORS
Q3501, 3502 RN1901
D3501, 3502 DAN202U
MISCELLANEOUS
CN3501–3504, 3506 40P CONNECTOR AKM1348
CN3505 18P CONNECTOR VKN1310
RESISTORS
R3519, 3520 RAB4C472J
R3521, 3522, 3525 RAB4C101J
R3524 RAB4C222J
Other Resistors RS1/16SS###J
[DIGITAL DD CON BLOCK]
SEMICONDUCTORS
IC3601 BA80BC0WFP
MISCELLANEOUS
U3601 DD CON UNIT AXY1137
RESISTORS
R3611 RAB4C101J
Other Resistors RS1/16SS###J
CAPACITORS
C3609 CKSSYB104K10
C3611 CKSQYB105K16
C3612 ACH1394
C3613 CKSSYB103K16
Mark No. Description Part No.
SENSOR ASSY
SEMICONDUCTORS
IC3651 MM1522XU
IC3652 BR24L02FJ-W
Q3651 HN1B04FU
MISCELLANEOUS
CN3651 CONNECTOR AKM1276
RESISTORS
Other Resistors RS1/16SS###J
CAPACITORS
C3651, 3653 CKSRYB105K6R3
C3652, 3654 CKSSYB103K16
C3656, 3657 CKSSYB104K10
50 X MAIN DRIVE ASSY
[50X LOGIC BLOCK]
SEMICONDUCTORS
IC1001 TC74ACT541FT
IC1002 TC74VHC00FTS1
D1001–1004 1SS355
MISCELLANEOUS
K1004, 1007 TEST PIN AKX1061
CN1001 18P CONNECTOR VKN1310
RESISTORS
R1001, 1006 RAB4C470J
R1004 RAB4C472J
VR1001 CCP1390
Other Resistors RS1/16S###J
CAPACITORS
C1001 CEHAT470M16
C1002, 1003 CKSRYB104K16
C1004 CCSRCH331J50
C1006 CCSRCH680J50
[50X RESONANCE BLCOK]
SEMICONDUCTORS
IC1101, 1105 TND307TD
IC1102 PS9117P
IC1104 AXF1163
IC1107 PS2701A-1(L)
Q1101 2SC2412K
Q1102, 1103 QSZ2
Q1104, 1105 2SC4081
D1101, 1103 UDZS5R6(B)
D1102 CRH01
D1104 UDZS15(B)
MISCELLANEOUS
L1101 ATH1217
L1106 ATH1216
F1101 CTF1449
1101 ANH1653
1102 AEH1092
1103 BMZ30P080FTC
