(1) PACKING PARTS LIST
(2) CONTRAST TABLE
PDP-5071PU/KUCXC and PDP-5070PU/KUCXC are constructed the same except for the following:
Mark
No. Description Part No.
>
1Power Cord (2 m) ADG1215
2 G-LINK Cable (3 m) VDX1010
3 Remote Control Unit AXD1536
4 Battery Cover AZN2680
5 Simpled Remote Control Unit See Contrast table (2)
6 Battery Cover See Contrast table (2)
NSP 7
Alkaline Dry Cell Battery (LR6, AA)
VEM1023
NSP 8 Dry Cell Battery (R03, AAA) See Contrast table (2)
9 Filter CTX1054
10 Binder Assy AEC1908
NSP 11 Hexagonal Wrench (6 mm) AEF1029
12 Cleaning Cloth AED1285
13 Operating Instructions ARE1426
(English, French, Spanish)
14 Caution Card ARM1239
15 Cleaning Caution (U) ARM1303
16 Accessory Caution ARM1304
NSP 17 Warranty Card ARY1196
NSP 18 Card (Register) ARY1156
19 Polyethlene Bag AHG1394
20 Vinyl Bag AHG1347
21 Pad (507REG. T-L) AHA2571
22 Pad (507REG. T-R) AHA2572
23 Pad (507REG. B-L) AHA2573
24 Pad (507REG. B-R) AHA2574
25 Pad (507EL. B-ACC.) AHA2575
26 Under Carton (507REG) AHD3484
27 Upper Carton (507REG) See Contrast table (2)
28 Packing Sheet L AHG1389
29 Polyethylene Bag S AHG1395
Mark
No. Description Part No.
Mark No. Symbol and Description
PDP-5071PU
/KUCXC
PDP-5070PU
/KUCXC
5 Simpled Remote Control Unit AXD1539 Not used
6 Battery Cover AZN2682 Not used
NSP 8 Dry Cell Battery (R03, AAA) VEM1036 Not used
27 Upper Carton AHD3485 AHD3523
