Pioneer PDP-5071PU User Manual

PDP-5071PU
127
5678
56
7
8
C
D
F
A
B
E
SUS-B ADJUSTMENT
50X MAIN DRIVE Assy
SUS-D ADJUSTMENT
XSUS-U
from
DIGITAL Assy
IC1001_A2
Pin
3
Pin
2
Pin
5
Pin
4
Pin
8
Pin 2
IC1102
IC1205
IC1101
IC1104
X DK
Module
Q1102
TP1106
Coupler
1 Measure the SUS-U input delay time (∆ Tsus-u).
from
DIGITAL Assy
XSUS-B
IC1001_A1
VR1001
Q1210
FET
Q1211
FET
Coupler
IC1204
Q1213
Q1209
TP1260
2 Adjust the SUS-B input delay time so that it becomes "∆ Tsus-u + α ± 5 nsec."
50Y MAIN DRIVE Assy
50Y MAIN DRIVE Assy
YSUS-U
from
DIGITAL Assy
IC2003_A4
Pin 2
IC2102
IC2209
IC2101
IC2107
Y DK
Module
Q2103
TP2105
Coupler
1 Measure the SUS-U input delay time (∆ Tsus-u).
1 Measure the SUS-D pulse width (Tsus-D).
from
DIGITAL Assy
YSUS-B
IC2003_A4
VR2001
Q2210
FET
Q2216
FET
Coupler
IC2208
Q2221
Q2215
TP2276
2 Adjust the pulse width of the SUS-D input signal for
the DK module so that it becomes "Tsus-D ± 5 nsec."
2 Adjust the SUS-B input delay time so that it becomes "∆ Tsus-u + α ± 5 nsec."
from
DIGITAL Assy
YSUS-D
IC2002_A7
Q2106
VR2002
IC2104
IC2107
Y DK
Module
TP2107
