(1) REAR SECTION PARTS LIST
(2) CONTRAST TABLE
PDP-5071PU/KUCXC and PDP-5070PU/KUCXC are constructed the same except for the following:
Mark
No. Description Part No.
1 SIDE KEY Assy AWW1133
2 SIDE Assy AWW1157
3• • • • •
4 USB Cable 120 cm (J301) ADF1034
5 Side Input Panel (U) ANC2392
6 Function Button Base ANG2923
7 Side Input Shield ANK1834
8 Function Button Shield ANK1835
NSP 9 PCB Support AEC1288
10 PCB Spacer AEC1570
11 Wire Saddle AEC1745
12 Re-use Wire Saddle AEC1945
13 Locking Card Spacer AEC2019
14 USB Spacer AED1310
15 Inner Grip Assy AMR3434
16 Gasket (USB) ANK1846
NSP 17 Name Label (507PU) See Contrast table (2)
18 Side Spacer 507 AED1311
19 Bolt Caution Label AAX3075
NSP 20 Serial Seal AAX3182
21 Side Spacer 507 AED1311
22 Terminal Display Label A (U/B) AAX3325
23 Terminal Display Label C (U/B) AAX3330
24
Ter minal Display Label B50 (U/B)
AAX3414
25 Terminal Panel B (50U) ANC2409
26 Function Button Panel AMB2906
27 Side Input Cover AMB2911
28 Function Button AAC1562
29 Function Button Sheet (U) AAK2895
30 Input Cover Label U AAX3363
31 Rear Case (507) ANE1656
32 • • • • •
33 Screw (3 x 40P) ABA1332
34 Screw ABA1341
35 • • • • •
36 Screw AMZ30P060FTB
37 Screw AMZ30P080FTC
38 Screw APZ30P080FTB
39 Screw BPZ30P080FTB
40 Screw TBZ40P080FTB
Mark
No. Description Part No.
Mark No. Symbol and Description
PDP-5071PU
/KUCXC
PDP-5070PU
/KUCXC
NSP 17 Name Label AAL2766 AAL2810
