Q2520 2SC2412K
D2501, 2503, 2510, 2516 CRH01
D2502, 2512, 2518 1SS301
D2504, 2508 UDZS4R7(B)
D2505, 2507, 2513, 2517 1SS355
D2509 D1FL40
D2511 1SS302
D2515, 2521 UDZS5R1(B)
D2519, 2520, 2523 1SS355
D2522 UDZS5R6(B)
D2524 UDZS15(B)
MISCELLANEOUS
T2501 ATK1156
T2502 ATK1161
T2503 ATK1159
RESISTORS
R2510, 2514, 2539, 2543 RS1/16S4701F
R2513 RAB4C472J
R2523 RS1/16S4702F
R2524, 2531 RS1/10S224J
R2530, 2532 RS1/16S1501F
R2533 RS3LMF151J
R2536 RS1/16S1002F
R2544 RS1/16S4701F
R2550 RS1/16S5601F
R2554 RS1/16S6801F
VR2501 CCP1390
Other Resistors RS1/16S###J
CAPACITORS
C2501, 2502, 2514 CEHAT101M25
C2503, 2515 ACG1105
C2504 CKSRYB102K50
C2505, 2506, 2512 CKSRYB104K16
C2507 CEHAT221M6R3
C2508 CEHAT221M25
C2509, 2510, 2518 CKSRYB103K50
C2511, 2516 CKSRYB105K6R3
C2513 CKSYB105K25
C2517 CKSRYF104Z50
C2519–2521, 2525 CKSRYB104K16
[50Y SCAN BLOCK]
SEMICONDUCTORS
IC2601–2603, 2607 TLP116
IC2604–2606 PS9117P
IC2610, 2611 TC74AC540FT
MISCELLANEOUS
L2601, 2611 BTH1134
CN2601 15P CONNECTOR AKM1200
RESISTORS
R2624 RAB4C220J
R2631 RS1/10S0R0J
Other Resistors RS1/16S###J
CAPACITORS
C2601, 2623 CEHAT101M10
C2602, 2603, 2611–2617 CKSRYB104K16
C2621, 2622 ACH1450
Mark No. Description Part No.
C2631 CKSRYB104K16
50 Y SUB DRIVE ASSY
SEMICONDUCTORS
Q2701 FKP280AS
Q2711 FKP300AS
Q2721, 2723, 2725, 2726 H5N2512LS
Q2731 QSZ2
D2701 CRH01
MISCELLANEOUS
F2701–2706 ATX1062
K2701 TEST PIN AKX1061
KN2701, 2702, 2711–2713 ANK1841
CN2701 14P CONNECTOR 14R-FJ
2702 SCREW PMB30P080FNI
RESISTORS
R2702, 2712 RS1/10S2R2J
R2722, 2724, 2726, 2727 RS1/10S100J
R2732 RS1/10S0R0J
Other Resistors RS1/16S###J
CAPACITORS
C2701 ACE1178
C2702 ACH1423
C2703 ACG1088
C2711, 2721 ACG1139
C2731 CKSYB105K25
[DRIVE HEAT SINK M]
MISCELLANEOUS
3001, 3001 ANH1656
3101, 3101 ANG2679
RESISTORS
All Resistors RS1/16S###J
MAIN ASSY
[BOARD IF BLOCK(U)]
SEMICONDUCTORS
IC4001–4005 TC74VCX541FT
Q4001, 4002 DTC124EUA
Q4003 RN2902
Q4004 DTA124EUA
MISCELLANEOUS
L4001–4005 BTX1042
F4001–4003, 4011–4016 CTF1557
F4005, 4006 VTF1084
CN4001, 4004 50P CONNECTOR AKM1349
CN4005 40P CONNECTOR AKM1348
CN4006 6P PLUG KM200NA6
CN4009 CONNECTOR AKM1274
CN4013 12P FFC CONNECTOR AKM1233
CN4018 3P CONNECTOR AKM1213
RESISTORS
R4001 RAB4CQ470J
R4002, 4018 RS1/16S102J
R4012, 4017, 4048 RS1/16S75R0F
R4016 RS1/16S0R0J
R4021–4024 BCN1067
