Printer Parts and Locations
The figure below calls out key printer components, each of which is
briefly described in the text that follows.
Print Station
Cover
Control Panel
Media Thickness
Knob
Separator Assembly
Input Guide
Feed Ramp
Feed Tires
Input Guide Angle
Adjustment Knob
Transport
Belts
Side
Guides
Feed Ramp
Adjustment
Lever
Exit
Rollers
Operator Guide
Holder Area
Stacker
Optional High Speed Stacker Connector
at back of Printer (not shown).
Optional Feeder
Connector on left
side of printer
(not shown)
