Planet HDP-1261PT User Manual

1080p SIP Vandalproof Door Phone with RFID and PoE
HDP-1261PT
14
OpenVPN
SNTP
FTP/TFTP
TR-069
Security
Web Filter, Transport Layer Security (TLS)
Secure Real-time Transport Protocol (SRTP)
NAT traversal: STUN mode
HTTP/HTTPS web server, HTTPS certificate manager
Firewall
Network and Provisioning
Network Interface
1 x 10/100BASE-TX RJ45 Ethernet interface, auto-MDIX
IP Configuration
Static/DHCP/PPPoE
Deployment/Maintenance
Auto provisioning: FTP/TFTP/HTTP/HTTPS/DHCP OPT66/SIP
PNP/TR-069
VLAN
Web Management
Web-based packet dump
Configuration backup/restore
Firmware Upgrade via Web
Syslog
PLANET DDNS and Easy DDNS
PLANET Smart Discovery Utility
Physical Interface
Keypad
1 DSS button (speed dial button)
Power Requirements
Power over Ethernet (IEEE 802.3af/at), class 3 and DC12V
Net Weight
493g
Dimensions (W x D x H)
88 x 36.15 x 177.4 mm
Emission
CE, FCC
Connectors
1 100M/10M RJ45 Ethernet
Short-in detection port x 3
 Port: Terminal socket
Short-out control port x 2 (built-in relay)
 Relay: Max. DC30V / 2A, AC125V / 0.5A
 Port: Terminal socket
Tamper switch x 1
TF card slot x 1: connect TF card, up to 128GB
RF Card Reader:125KHz & 13.56MHz
RS485 (Reserved for future use)
Wiegand Port: In/Out configurable, Wiegand in by default
