Planet HDP-1261PT User Manual

1080p SIP Vandalproof Door Phone with RFID and PoE
HDP-1261PT
13
1.4 Specifications
Product
HDP-1261PT
Access Control
Door Access
Dual SIP line, Dual SIP servers
DTMF tones,
RFID /IC card: ID (EM4100,125KHz) & IC (MIFARE ONE,13.56MHz)
 Supports up to 10,000 RFID cards.
 Records door open events with a capacity of 200,000
entries
Door Phone features
Full-duplex
Default auto answer
Action URL/Active URI remote control
Speed Dial
Video
Image Device
2MP color CMOS camera
Max. Image Transfer Rate
1080p -30fps (1080p expected to be launched by firmware upgrade in
2024/Q1)
Video Codec
H.264
Resolution
Main stream 1080P@30fps
Sub stream VGA@30fps
Viewing Angle
120° (H), 60° (V) , 141° (D)
Minimum illumination
0.1Lux, support for infrared illumination
IR Illuminations
IR LED x 4, effective up to 5 meters
*The IR distance is based on the environment.
Audio
Audio Streaming
HD voice
Two-way audio stream
Microphone
Built-in microphone and speaker
Narrowband Codec
G.711A/U, G.729A/B,iLBC,G.723.1,G.726-32K
Wideband Codec: G.722, Opus
DTMF
In-band, Out-of-Band (RFC2833/ SIP INFO)
Audio Output
Acoustic Echo Cancellation (AEC) audio output
Protocol and Security
Protocols
SIP v1 (RFC2543), v2 (RFC3261) over UDP/TCP/TLS
RTP/RTCP/SRTP
ONVIF
STUN
DHCP
IPv6
PPPoE
L2TP
