Planet HDP-1261PT User Manual

1080p SIP Vandalproof Door Phone with RFID and PoE
HDP-1261PT
85
5.38 EGS Setting >> Features
Figure 5-38-1 ESG Feature Setting Page Screenshot
You can set basic access control settings on this screen
Field Name
Explanation
Basic Settings
Relay1 Mode
Monostable: There is only one fixed action status for door unlocking.
Bistable: There are two actions and statuses, door unlocking and door locking.
Each action might be triggered and changed to the other status. After the
change, the status would be kept.
Initial Value is Monostable.
Relay1 Duration
Door unlocking time for Monostable mode only. If the time is up, the door would
be locked automatically. Initial Value is 5 seconds.
Relay2 Mode
Monostable: There is only one fixed action status for door unlocking.
Bistable: There are two actions and statuses, door unlocking and door locking.
Each action might be triggered and changed to the other status. After the
change, the status would be kept.
Initial Value is Monostable.
Relay2 Duration
Door unlocking time for Monostable mode only. If the time is up, the door would
be locked automatically. Initial Value is 5 seconds.
