Planet HDP-1261PT User Manual

1080p SIP Vandalproof Door Phone with RFID and PoE
HDP-1261PT
86
Relay2 Mode
Monostable: There is only one fixed action status for door unlocking.
Bistable: There are two actions and statuses, door unlocking and door locking.
Each action might be triggered and changed to the other status. After the
change, the status would be kept.
Initial Value is Monostable.
Relay2 Duration
Door unlocking time for Monostable mode only. If the time is up, the door would
be locked automatically. Initial Value is 5 seconds.
Relay2Follow mode
Independent: Open the door independently with Relay 1.
Synchronous: Open the door at the same time as Relay1.
Asynchronous: Relay1 opens after a period of time Relay2 opens.
Asynchronous delay
The user can set the asynchronous door opening delay time of Relay1 and
Relay2, the default is 1 second.
RFID card format
Supported access control card format
Wiegand format
Supported Wiegand access card format
Wiegand mode
Optional input port or output port, default in
Wiegand Type
Supports 26 and 34
Enable Card Reader
Enable or disable card reader for RFID cards.
Card Reader
Working Mode
Set ID card stats:
Normal: This is the work mode where the slot card can open the door.
Card Issuing: This is the issuing mode where the slot card can add ID cards.
Card Revoking: This is the revoking mode where the slot card can delete ID
cards.
