Planet HDP-1261PT User Manual

1080p SIP Vandalproof Door Phone with RFID and PoE
HDP-1261PT
87
5.39 EGS Setting >> Relay
Figure 5-39-1 Relay Setting Page Screenshot
Field Name
Explanation
Relay Status
Door Sensor1
Enable or disable door sensor 1.
Door Sensor Check Delay 1
Door Sensor1 detection delay time setting, 5 seconds by default.
Door Sensor2
Enable or disable door status sensor 2.
Door Sensor Check Delay 2
Door Sensor2 detection delay time setting, 5 seconds by default.
Lock Status 1
Door Close/Open
Door Sensor Status1
Door Close/Open
Lock Status 2
Door Close/Open
Door Sensor Status2
Door Close/Open
Door Lock Control
Door Lock
Execute a door lock to open or close the door
Action
Door Open/Close
Open mode
The door will close automatically when time is out.
The door will not close automatically and need to close manually when
time is out.
