Planet HDP-1261PT User Manual

1080p SIP Vandalproof Door Phone with RFID and PoE
HDP-1261PT
16
Chapter 2. Hardware Interface
2.1 Physical Descriptions
Product Dimensions (W x D x H)
88 x 36.15 x 177.4 mm
Net Weight
493g
Front Panel
Number
Interface
Description
1
Camera
The door phone has a built-in IP camera supporting a high-resolution
video of up to 1920 x 1080 pixels.
2
Mic
The door phone has a built-in microphone hidden in the pinhole
located on the front panel.
3
IR LED
The door phone provides 4 IR LEDs for clear image in low light
condition.
4
DSS Key
For speed dial, multicast, intercom, IP broadcast and other functions.
(Function can be set by user.)
5
RFID Sensor
Use the corresponding RFID door card to open the door by swiping
the card. With one beep sound, the door is opened.
6
Speaker
The door phone has a built-in speaker for convenient communication
and alert use.
7
Distance Sensor
The distance between the sensing device and the object.
8
Photosensitive
Sensor for image enhancement.
