Planet HDP-1261PT User Manual

1080p SIP Vandalproof Door Phone with RFID and PoE
HDP-1261PT
56
Parameters
Description
Dial rule
There are two types of matching: Full
Matching or Prefix Matching. In Full
matching, the entire phone number is
entered and then mapped per the Dial Peer
rules.
In prefix matching, only part of the number is
entered followed by T. The mapping with
then take place whenever these digits are
dialed. Prefix mode supports a maximum
of 30 digits.
Note: Two different special characters are used.
 x -- Matches any single digit that is dialed.
 [ ] -- Specifies a range of numbers to be matched. It may be a range, a list of ranges
separated by commas, or a list of digits.
Destination
Set Destination address. This is for IP direct.
Port
Set the Signal port, and the default is 5060
for SIP.
Alias
Set the Alias. This is the text to be added,
replaced or deleted. It is an optional item.
Note: There are four types of aliases.
 all: xxx – xxx will replace the phone number.
 add: xxx – xxx will be dialed before any phone number.
 del –The characters will be deleted from the phone number.
 rep: xxx – xxx will be substituted for the specified characters.
Suffix
Characters to be added at the end of the
phone number. It is an optional item.
Length
Set the number of characters to be deleted.
For example, if this is set to 3, the phone will
delete the first 3 digits of the phone number.
It is an optional item.
This feature allows the user to create rules to make dialing easier. There are several different options for
dialing rules. The examples below will show how this can be used.
