User Manual of WAP-252N/WAP-552N
-7-
Product Specifications 1.4
Model Name
WAP-252N WAP-552N
Description
2.4GHz 802.11n 300Mbps Outdoor
Wireless AP
5GHz 802.11n 300Mbps Outdoor Wireless
AP
Hardware Features
Interfaces
Wireless IEEE802.11b/g/n, 2T2R
Wireless IEEE 802.11a/n, 2T2R
PoE: 1 x 10/100BASE-TX, auto-MDI/MDIX, 802.3af/at PoE In
LAN: 1x 10/100BASE-TX, auto-MDI/MDIX
Antennas Two built-in N-type connectors
Material Aluminum
IP Level
IP67
Dimensions
153.2 x 79.5 x 234.5 mm
Weight
2kg
Power Requirements
48V 0.5A, IEEE 802.3af/at PoE+
Power Consumption
< 13W
Mounting Type
Mast mounting
Button
Reset/Pair button
Wireless Interface Specifications
Standard
IEEE 802.11b/g/n
IEEE 802.11i
IEEE 802.3 10BASE-T
IEEE 802.3u 100BASE-TX
IEEE 802.3x flow control
IEEE 802.11a/n
IEEE 802.11i
IEEE 802.3 10BASE-T
IEEE 802.3u 100BASE-TX
IEEE 802.3x flow control
Media Access Control
CSMA/CA
Modulation
802.11g/n: OFDM (BPSK/ QPSK/
16QAM/ 64QAM)
802.11b: DSSS (DBPSK/ DQPSK/
CCK)
802.11a/n:
OFDM (BPSK/ QPSK/ 16QAM/
64QAM)
Frequency Band
FCC: 2.412~2.462GHz
ETSI: 2.412~2.472GHz
FCC: 5.180~5.240GHz, 5.745~5.825GHz
ETSI: 5.180~5.700GHz
Operating Channels
FCC: 1~11 Channels
ETSI: 1~13 Channels
FCC: 36, 40, 44, 48, 149, 153, 157, 161,
165 (9 channels)
ETSI: 36, 40, 44, 48, 52, 56, 60,
64, 100,
104, 108, 112, 116, 132, 136, 140 (16
channels)
5GHz channel list will vary in different
countries according to their
regulations.
Max. Transmit Power
(dBm)
FCC: up to 29 ± 1dBm
ETSI: < 20dBm (EIRP)
FCC: up to 27 ± 2dBm
ETSI: < 20dBm (EIRP)
