User Manual of WAP-252N/WAP-552N
-10-
Chapter 2. Hardware Introduction
Physical Specifications 2.1
Physical Specifications
Dimensions (W x D x H)
153.2 x 79.5 x 234.5mm
Weight
2kg
Appearance
2.1.1 Hardware Description
Hardware Interface Definition
Object Description
Antenna Connectors
2 N-type (female) antenna connectors
PoE LAN Port
10/100Mbps RJ45 port, auto MDI/MDI-X
802.3af/at PoE+ supported, 48VDC In
Reset Button
Press and hold the Reset button on the PCBA for over 15 seconds to
return to the factory default setting.
