User’s Manual of WGSW-24040 / WGSW-24040R
SGSW-24040 / SGSW-24040R
240
Default Setting:
1
Example:
Set mirror SID 2 for switch
SWITCH/>mirror sid 2
Mirror Mode
Description:
Set or show the mirror mode.
Syntax:
Mirror Mode [<port_list>] [enable|disable|rx|tx]
Parameters:
<port_list>: Port list or 'all', default: All ports
enable : Enable Rx and Tx mirroring
disable: Disable Mirroring
rx : Enable Rx mirroring
tx : Enable Tx mirroring
(default: Show mirror mode)
Default Setting:
Disable
Example:
Enable mirror mode for port20
SWITCH/>mirror mode 20 enable
