User’s Manual of WGSW-24040 / WGSW-24040R
SGSW-24040 / SGSW-24040R
250
Dot1q
Example:
Set VLAN mode in port base
SWITCH/>vlan mode portbased
VLAV PVID
Description:
Set or show the port VLAN ID.
Syntax:
VLAN PVID [<port_list>] [<vid>|none]
Parameters:
<port_list>: Port list or 'all', default: All ports
<vid>|none : Port VLAN ID (1-4095) or 'none', default: Show port VLAN ID
Default Setting:
1
Example:
Set PVID2 for port20
SWITCH/>vlan pvid 20 2
VLAN Frame Type
Description:
Set or show the port VLAN frame type.
Syntax:
VLAN FrameType [<port_list>] [all|tagged]
Parameters:
<port_list>: Port list or 'all', default: All ports
all : Allow tagged and untagged frames
tagged : Allow tagged frames only
