User’s Manual of WGSW-24040 / WGSW-24040R
SGSW-24040 / SGSW-24040R
91
Figure 4-5-3 Aggregation Group Configuration page screenshot
The page includes the following fields:
.
Object Description
• Locality
Indicates the aggregation group type. This field is only valid for stackable
switches.
• Global: The group members may reside on different units in the stack. The
device supports two 8-port global aggregations.
• Local: The group members reside on the same unit. Each local
aggregation may consist of up to 16 members.
• Group ID
Indicates the group ID for the settings contained in the same row. Group ID
"Normal" indicates there is no aggregation. Only one group ID is valid per port.
• Port Members
Each switch port is listed for each group ID. Select a radio button to include a port
in an aggregation, or clear the radio button to remove the port from the
aggregation. By default, no ports belong to any aggregation group.
