User’s Manual of WNRT-627
-14-
Supports Wi-Fi Protected Setup (WPS)
Advanced security: 64/128/152-bit WEP, WPA/WPA2 and
WPA-PSK/WPA2-PSK(TKIP/AES encryption), 802.1x
Supports NAT firewall features, with SPI function to protect against DoS attacks.
Supports IP / Protocol-based access control and MAC Filtering
Advanced Networking function for Specific Application
Supports multiple sessions IPSec, L2TP and PPTP VPN pass-through
Supports Virtual Server, ALG, DMZ and UPnP for various networking applications
Supports DHCP Server
Easy Installation & Management
Web-based UI for Quick setup for easy configuration
Remote Management allows configuration from a remote site
System status monitoring includes DHCP Client, System Log
1.4 Product Specifications
Product
WNRT-627
300Mbps 802.11n Wireless Broadband Router
Hardware Specifications
WAN Port: 1 x 10/100Mbps Auto MDI/MDI-X RJ45 port
Interface
LAN Port: 4 x 10/100Mbps Auto MDI/MDI-X RJ45 ports
Gain: 2 x Fixed 5dBi Antenna
Antenna
Orientation: Omni-directional
Power Button Power On/Off button at rear panel
WPS / Reset Button
WPS / Reset button at front panel
Push for above 5 seconds to reset to factory default setting
LED Indicators PWR, SYS, WLAN, LAN x 4, WAN, WPS with green light
Material Plastic
Wireless Interface Specifications
Standard Compliance with IEEE 802.11b/g/n
Frequency Band
2.4~2.4835GHz
Extended Frequency
DSSS
Modulation Type
DBPSK, DQPSK, QPSK, CCK and OFDM (BPSK/QPSK/16-QAM/ 64-QAM)
Data Transmission
Rates
11n: 135/121.5/108/81/54/40.5/27/13.5Mbps
130/117/104/78/52/39/26/13Mbps
65/58.5/52/39/26/19.5/13/6.5Mbps (Dynamic)
11g: 54/48/36/24/18/12/9/6Mbps (Dynamic)
11b: 11/5.5/2/1Mbps (Dynamic)
Transmission Indoor up to 100m
