User’s Manual of WNRT-627
-19-
2.1.3 The Rear Panel
Figure 2-3 Rear Panel
Interface Function
POWER
The Power socket is where you will connect the power adapter.
Please use the power adapter provided with WNRT-627.
ON/OFF The button of the power.
WAN Connect to the DSL/cable Modem, or Ethernet
1,2,3,4 (LAN) Connect to the user’s PC or network devices
Table 2-2 The Interface indication
