User’s Manual of WNRT-627
-56-
5.5.2 LAN
Choose menu “Network→LAN”, you can configure the IP parameters of the LAN on the screen as
below.
Figure 5-16 LAN Settings
The page includes the following fields:
Object Description
The physical
address of the Router, as seen from the LAN. The value
can't be changed.
MAC Address
Enter the IP
address of your Router or reset it in dotted-decimal notation
(factory default: 192.168.1.1).
IP Address
An addre
ss code that determines the size of the network. Normally use
255.255.255.0 as the subnet mask.
Subnet Mask
Table 5-9
1. If you change the IP Address of LAN, you must use the new IP Address to
login the Router.
2. If the new LAN IP Address you set is not in the same subnet, the IP Address
pool of the DHCP server will change accordingly at the same time，while the
Virtual Server and DMZ Host will not take effect until they are re-configured.
