User’s Manual of WNRT-627
-79-
Figure 5-37 Virtual Servers
The p
age includes the following fields:
Object Description
The numbe
rs of External Ports. You can type a service port or a range of
service ports (in XXX – YYY format, XXX is the start port number, YYY is
the end port number).
Service Port
The IP
Address of the PC providing the service application.
IP Address
Protocol
The protocol used for this application, either TCP, UDP, or All (all protocols
supported by the Router).
The status of
this entry either Enabled or Disabled.
Status
Table 5-24
To set up a virtual server entry:
Step 1. Click the Add New… button.
Step 2. Select the service you want to use from the Common Service Port list. If the Common
Service Port list does not have the service that you want to use, type the number of the service
port or service port range in the Service Port box.
Step 3. Type the IP Address of the computer in the IP Address box.
Step 4. Select the protocol used for this application, either TCP or UDP, or All.
Step 5. Select the Enable check box to enable the virtual server.
