39-10
Configure interface vlan3 IPv6 address and affiliated OSPFv3 area
SwitchD#config
SwitchD(config)# interface vlan 3
SwitchD(config-if-vlan3)# IPv6 address 2030:1:1::2/64
SwitchD(config-if-vlan3)# IPv6 router ospf area 0
SwitchD(config-if-vlan3)#exit
SwitchD(config)#exit
SwitchD#
Layer 3 SwitchE:
Startup OSPFv3 protocol, configure router ID
SwitchE(config)#router IPv6 ospf
SwitchE(config-router)#router-id 192.168.2.5
Configure interface IPv6 address and affiliated OSPFv3 area
SwitchE#config
SwitchE(config)# interface vlan 2
SwitchE(config-if-vlan2)# IPv6 address 2100:1:1::2/64
SwitchE(config-if-vlan2)# IPv6 router ospf area 0
SwitchE(config-if-vlan2)#exit
Configure interface VLAN3 IPv6 address and affiliated area
SwitchE(config)# interface vlan 3
SwitchE(config-if-vlan3)# IPv6 address 2030:1:1::1/64
SwitchE(config-if-vlan3)# IPv6 router ospf area 0
SwitchE(config-if-vlan3)#exit
SwitchE(config)#exit
SwitchE#
39.4 OSPFv3 Troubleshooting
In the process of configuring and implementing OSPFv3, physical connection, configuration false probably
leads to OSPFv3 protocol doesn’t work. Therefore, the customers should give their attention to it:
First of all, to ensure correct physical connection;
Secondly, to ensure interface and link protocol are UP (execute show interface instruction);
And configure IPv6 address of the different net segment on every interface.
To startup OSPFv3 protocol (execute router IPv6 OSPF instruction), and configure affiliated OSPFv3
area on relative interface.
And then, consider OSPFv3 protocol characteristic —— OSPFv3 backbone area (area 0) must be
continuous. If it doesn’t ensure that virtual link is implemented continuously, all of not area 0 only can be
connected by area 0 and other not area 0, not directly connected by not area 0; The border Layer 3
