131
MAINTENANCE
General Maintenance
NOTE: Do not touch a halogen bulb with bare fingers. Oil from skin
leaves a residue, causing a hot spot which will shorten the life of t he
lamp.
Removing the Side Bulbs
1 Disconnect terminal from
back of bulb.
2 Turn bulb assembly 1/4 turn
to right and withdraw from
housing.
Installing the Side Bulbs
1 Hold bulb assembly by
plastic base and plug into
wire terminal.
2 Insert bulb assembly into
housing.
3 Turn bulb assembly 1/4 turn
to left to secure in housing.
4 Verify headlight operation.
Wrap Around Taillight Bulb Replacement
1 Remove phillips screws from the taillight lens (A).
2 Working from
front to back, carefully pry lens away from seal and remove lens.
3 Pull bulb(s) (B) straight out from socket and insert new bulb(s).
4 Reinstall lens.
B
A
