Polaris 2002 Snowmobile - Track Maintenance; Track Tension Data

140
MAINTENANCE
Track Maintenance
Track Tension Data
Suspension
(See Owner’ s
Manual Supplement
for type)
Weight Measurement
Location
Measurement
XTRA 12 121″ none 2″ behind rail bumper 1/2″ (1.2 7 cm)
free hanging
XTRA 12 133″ none 16″ ahead of rear
idler shaft
1-1 1/8″ (2.54 - 2.8 6
cm)
free hanging
XTRA 10 121″, 133″,
136”
10 lbs. (4.54 kg) 16″ ahead of rear
idler shaft
3/8 - 1/2″ (1 - 1.3 cm)
WideTrak Type 10 lbs. (4.54 kg) 16″ ahead of rear
idler shaft
3/4 - 1″ (1.9 - 2.5 cm)
XTRA Lite 121″,
133″ , 136″
10 lbs. (4.54 kg) 16″ ahead of rear
idler shaft
3/8 - 1/2″ (1 - 1.3 cm)
Edge RMK 136″ 10 lbs. (4.54 kg) 16″ ahead of rear
idler shaft
3/8 - 1/2″ (1 - 1.3 cm)
Edge RMK 144″ 10 lbs. (4.54 kg) 16″ ahead of rear
idler shaft
1/2 ″ -3/4″ (1.9)
Edge RMK 151″ 10 lbs. (4.54 kg) 16″ ahead of rear
idler shaft
1/2 ″ -3/4″ (1.9)
Edge RMK 156″ 10 lbs. (4.54 kg) 16″ ahead of rear
idler shaft
1/2 ″ -3/4″ (1.9)
Edge 10 lbs. (4.54 kg) 16″ ahead of rear
idler shaft
3/8 - 1/2″ (1 - 1.3 cm)
M-10 Refer to your M-10 Owner’s Manual Supplement
