1.45
General Information
1
NOTE: * = Rider weight in everyday clothing.
** = From full soft (CCW) position.
Track
Width - Inches (cm) 15 (38)
Length - Inches (cm) 121 (307)
Pitch
Plies
2.52
2
Lug Height - Inches (cm)
Base
PRO-R
PRO-R (International)
1.0 (2.54) (Hacksaw)
1.25
(3.175) (Ripsaw)
1.352 (3.43) (Cobra)
Track Tension
1/4
- 3/8(6.3 - 9.6mm)
Electrical
Alternator Output
Operating Voltage
Watts @ 13.5 VDC (Total)
13.5 - 14.5 VDC
400
Ignition Timing
18° @1700 RPM
Co
olant Temp = 120° F (49° C)
Spark Plug Gap in.(mm) .027 (.70)
Spark Plug NGK BPR9ES
Front Suspension
Suspension Type PRO-RIDE (Fixed Camber)
Shocks
Base
PRO-R
Fox HPG w/IFP
W
alker Evans Needle Piggyback
16 Click Compression Adjustable
Factory Setting** = 6
IFS Spring Rate
lbs/in (N/mm)
80 (14)
Preload - Inches (cm)
Base
PRO-R
3.75 (9.52)
3.
0 (7.6)
Travel-Inches (cm) 9 (22.9)
Ski Center Distance
Inches (cm)
Setup Width
42.5 (108)
41
.52 (105)
Toe Out Inches (mm) 0 -1/8 (0
- 3)
Rear Suspension
Suspension Type PRO-RIDE Progressive
Front Track Shock
(FTS)
Base
PRO-R
Fox HPG w/IFP
W
alker Evans w/Remote Reservoir
16 Click Compression Adjustable
Factory Setting** = 2
FTS Spring Rate
lbs/in (N/mm)
120 - 310 (21 - 54.25)
FTS Spring Preload
Inches (cm)
2.0 (5.08)
Rear Track Shock
(RTS)
Base
PRO-R
Fox HPG w/IFP
W
alker Evans Needle
w/Remote Reservoir
16 Click Compression Adjustable
Factory Setting** = 4
Standard RTS Spring
Rider Weight*
120 - 260lbs.
Rate lbs/in (N/mm)
PN: 7043195-133
1
70 (29.75)
LW RTS Spring
Rider Weight*
90 - 150lbs.
Rate lbs/in (N/mm)
PN: 7041575-385
120
(21)
HD RTS Spring
Rider Weight*
240 - 335+lbs.
Rate lbs/in. (N/mm)
PN: 7043585-385
2
60 (45.5)
RTS Spring
Rider / Weight Setting
Spring length set to rider weight
using
adjustment gauge.
STD Gauge PN: 9923267
STD gauge supplied with vehicle. LW
and HD springs - Use tape measure
and RTS Spring Guide Table located
in the Steering/Suspension Chapter.
Rear Travel
Inches (cm)
14 (35.6)
