7.12
9929422 R02 - 2017-2019 ACE 900 Service Manual
© Copyright Polaris Industries Inc.
5. Torque wheel hub nut to specification and install a
new cotter pin
y
. Tighten nut slightly if necessary to
align cotter pin holes.
TORQUE
Hub Castle Nut:
110 ft-lbs (149Nm)
6. Install wheel and four wheel nuts. Torque wheel nuts
to specification.
TORQUE
Wheel Nuts:
30 ft-lbs + 90° (41 Nm)
7. Rotate wheel and check for smooth operation. Bend
both ends of cotter pin around end of spindle in
different directions.
FINAL DRIVE
