7.6
FINAL DRIVE
Front Hub Exploded View
18 ft. lbs. (24 Nm)
Use new bolts with
pre-applied
locking agent.
Disc Brake
Stud
Front Hub
Rim
Tire
Wheel Nut
Dust Cover
Cotter Pin
Washer
Slotted Nut
70 ft. lbs. (95 Nm)
(Spec on page 7.3)
