8.17
TRANSMISSION
8
Exploded View (4x4, 6x6), Cont.
Ref. Qty. Description Ref. Qty. Description
1 Asm., 4x4 Transmission 35. 1 22T Sprocket
1. 1 Nut 36. 1 19T Sprocket
2. 1 Shift Drum Bellcrank 37. 1 Silent Chain
3. 5 Cover Screws 38. 1 Front Main Output Shaft
4. 1 Sector Cover 39. 1 Gear Set - 10T / 31T
6. 1 O-ring 40. 1 Ball Bearing
7. 1 Detent Pawl 41. 1 Spacer
8. 1 Compression Spring 42. 1 Retaining Ring
9. 1 Shift Shaft 43. 1 Bearing Center Drive Cover
10. 1 31T Sector Gear 44. 4 Torx Screws
11. 2 Hollow Hex Plug 45. 1 56T Mid Output Helical Gear (6x6: 60T Gear)
12. 2 Triple Lip Seal 46. 4 Ball Bearing
13. 1 Gearcase, Main 47. 1 Reverse Shaft
14. 1 Vent Tube 48. 1 Needle Cage Bearing
15. 1 O-Ring 49. 1 24T 6 Face Sprocket
16. 1 Shift Drum 50. 1 Washer
17. 1 External Retaining Ring 51. 2 External Retaining Ring
18. 1 6-Pin Switch 52. 4 6 Face Engagement Dog
19. 1 O-ring 53. 2 Wave Spring
20. 1 Detent Star 54. 1 Washer
21. 1 Lockout Disc 55. 2 Needle Cage Bearing
22. 1 16T Sector Gear 56. 1 28T 6 Face Gear (6x6: 23T Gear)
23. 2 Lock Nut 57. 1 51T Mid Output Helical Gear (6x6: 47T Gear)
24. 4 Dowel Pin 58. 1 Shift Shaft Rail
25. 4 Ball Bearing 59. 2 Shift Fork w/Pin
26. 1 Thrust Washer 61. 1 Silent Chain
27. 1 Vent Plug Cap 62. 1 Input Shaft Assy.
28. 1 Output Shaft 63. 1 LH Main Cover
29. 1 Shim 64. 1 Dual Lip Seal
30. 1 Thrust Button 65. 1 Transmission Mount Bracket
31. 1 Shim 66. 2 Hex Screw
32. 1 Output Cover 67. 1 33T 6 Face Gear
33. 15 Screw 68. 1 Washer
34. 1 Plain Bearing 69. 1 Label
To Next Page
