Repair Manual
Macro 5 SLR Camera
19
Specifications (Cont’d)
Magnification: Lens-to-subject Lens focal Effective lens Depth
distance length
2
aperture of field
3
0.2x (20%) 52in./130cm 221mm f/20 10.6in./27cm
0.4x (40%) 26in./66cm 188mm f/34 3.8in./10cm
1x (100%) 9.9in./25cm 128mm f/47 0.86in./2.2cm
2x (200%) 4.8in./13cm 85.4mm f/67 0.31in./0.8cm
3x (300%) 3.1in./8cm 64mm f/100 0.20in./0.5cm
Viewfinder Built-in grid screen for consistent
framing of subjects.
Rangefinder Dual-lights for focusing.
Memory Internal electronic memory. Camera returns to
custom settings for each magnification when it
is turned on.
Weight 4 lbs. (1.8kg)
Dimensions Height- 9 inches (23cm)
Width - 9 inches (23cm)
Depth - 8.7 inches (22cm)
Accessories Polarizer Kit:
Reduces reflections from flash units when
taking pictures of glossy or glass subjects.
Fluorescein Kit:
For external ophthalmic photography includes
#2A yellow barrier filter and #47A blue exciter
filters.
