Polaroid Macro 5 SLR - Figure 5-3 Front Cover; Front Cover; Removal (Figure 5-3)

Repair Manual
Macro 5 SLR Camera
43
Front Cover
1. Removal (Figure 5-3)
a. Remove the left/right cover assembly as explained on page 39.
b. Using a torx driver, remove the four (4) screws securing the front cover to
the left/right covers.
c. Lift off the front cover.
Figure 5-3 Front Cover
Left Cover
Right Cover
Front Cover
