Repair Manual

Macro 5 SLR Camera

Features

Camera

Basic Macro 5 SLR features include: (Figure 1-2)

• Camera Back (Film Holder)

• Film Door Release Button

• Two Built-In Electronic Flash Units

• Lens

• Dual Light Rangefinder (Ranging Lights)

• Viewfinder

• Grid Screen in Viewfinder

• Tripod or Copystand Socket (on bottom of camera)

• Battery Compartment Door

• Battery Compartment (inside hand grip)

• Right/Left Hand Grips

• Magnification Selector Knob

• Shutter (S1) Button

Table 1-1 describes the Macro 5 SLR features.

Table 1-1. Macro 5 SLR Camera Features

Camera Feature Description

Camera Back The camera back is a modified ProCam

camera back.

Film Door The film door release button opens the

Release Button camera back film door.

Lens The camera contains separate lens for

each magnification setting. Each lens has

the proper focal length for minimum

perspective distortion and more working

space between the camera and the subject,

and a small aperture for better depth of

field.
