Repair Manual
Macro 5 SLR Camera
38
Electrostatic Discharge Warning
The camera circuitry can easily be damaged by static discharges. Always use an
anti-static mat and a wrist-strap when servicing the camera's PC Boards.
Inspection and Cleaning
Whenever disassembling the camera for parts replacement, always inspect the
following assemblies for dust and debris (reagent developer).
Note: If necessary, clean the replaced parts with a water dampened tissue or
soft clean rag to assure that dust and debris (reagent developer)
do not interfere with camera performance.
• Front Cover Assembly
• Camera Back Rollers
• Turret Assembly
• Cone Assembly
• Shutter Assembly
• Viewfinder Assembly
Disassembly/Assembly of Camera
This section of the Service Manual describes disassembly/reassembly
procedures. Before performing any of these procedures, always make sure that
the camera is turned off and the film pack is removed.
CAUTION
To prevent any chance of electric shock, the camera should be opened only by
a qualified service person, and only after it has been disconnected from its
power source (film pack battery); make sure the strobe capacitors are fully
discharged (dumped). Also, take care not to damage (bend or distort) any of
the camera components during disassembly and reassembly.
