Repair Manual
Macro 5 SLR Camera
51
Trigger PC Boards
Note: Use a dump stick to fully discharge the strobe capacitors before
attempting to remove or replace the trigger PC board.
1. Removal (Figure 5-7)
a. Remove the left/right cover assembly as explained on page 39.
b. Remove the front cover assembly as explained on page 43.
c. Disconnect electrical cable J32 from the applicable trigger PC board.
d. Using a soldering iron and a solder sucker, unsolder the white trigger wire
from the trigger coil.
Note: Be careful not to damage the trigger coil.
e. Using a torx driver, remove the two (2) screws securing the trigger PC
board to the front cover support mounts.
f. Lift out the trigger PC board.
Caution: Shock Hazard - High Voltage
