User Guide for the SoundPoint IP 670 Desktop Phone
1 - 8
To attach the base as a wall mount:
1. Place all cords in the recessed area above the modular jacks.
2. On the back of the phone, remove the key located behind the hookswitch
and reposition it so that the end tab (at a 45
0
angle) is facing up.
3. With mounting tab of the base unit facing up, fasten the base unit to the
wall mount using wall anchors (not included).
Note
The wall mount is not included in SoundPoint IP 670 package. Contact your system
administrator if you require one.
