Polycom SoundPoint IP 670 User Manual

User Guide for the SoundPoint IP 670 Desktop Phone
2 - 2
Configuring Basic Settings
You can configure the following basic settings through use of :
• Appearance of the time and date
• Display contrast
• Backlight intensity
• Headset Memory Mode
• Headset hookswitch selection
• Ring type
• Language support (localization)
• Background pattern
• Soft key label color
You can mute the microphone and adjust the volume using separate keys.
Changing the Appearance of Time and Date
The time and date appears on the graphic display of the SoundPoint IP 670
phone. If the phone cannot obtain a time and date from the call server, the
display will flash. Contact your system administrator if either the time or date
is incorrect.
You can select from various formats for the time and date display. Select and
set options that are right for you. You can also disable the time and date
display, so the time and date do not display on the phone screen.
To configure the time and date formats:
1. Press .
2. Select Settings > Basic > Preferences > Time & Date.
3. Select from Clock Date, Clock Time, Clock Order, or Enable/Disable.

Polycom SoundPoint IP 670 Specifications

General

Voice codecs	G.711, G.722, G.729
Noise reduction	Yes
Microphone frequency	150 - 7000 Hz
Caller ID	-
Phonebook capacity	- entries
Security algorithms	HTTPS
Supported network protocols	SNTP/FTP/TFTP/HTTP
Display resolution	320 x 160 pixels
Ethernet LAN (RJ-45) ports	2
Product type	IP Phone
Product color	Gray
Dimensions (WxDxH)	265 x 190 x 150 mm
Storage temperature (T-T)	-40 - 70 °C
Operating temperature (T-T)	10 - 40 °C
Operating relative humidity (H-H)	20 - 85 %
Certification	FCC, RoHS, CE
Harmonized System (HS) code	85171800

Weight and Dimensions

Weight	1260 g
